92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power

92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power
92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power 92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power 92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power 92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power

Ampliación de imagen :  92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power

Datos del producto:
Lugar de origen: PORCELANA
Nombre de la marca: GNEE
Certificación: SGS
Pago y Envío Términos:
Cantidad de orden mínima: ≥1sets
Precio: 25 every month
Detalles de empaquetado: Embalaje de caja de madera
Condiciones de pago: L/C, D/A, T/T, D/P, Western Union, Moneygram
Contacto

92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power

descripción
Tecnología: Adsorción de balanceo de presión de vacío (VPSA) Caudal: 100-10000 nm3/h
Método de colocación: Vertical Tiempo de lanzamiento: 15-30 minutos
Presión de prueba: 0.8MPA-1.6MPA Potencia del compresor de aire: 22-110KW
Palabras clave: Generador del oxígeno de VPSA Color: Brillante o personalizado
Consumo: De ahorro de energía Tasa de llenado: 95%
Resaltar:

92.5%-93.5% High Purity VPSA Oxygen Generator

,

15-30 minutes Start-Up Time Oxygen Production Equipment

,

22-110kW Air Compressor Power Oxygen Plant

92.5%-93.5% High Purity VPSA Oxygen Generator
Product Description

The Vacuum Pressure Swing Adsorption (VPSA) Oxygen Generator utilizes a specialized mixed bed of VPSA molecular sieve and desiccant to selectively adsorb nitrogen, CO₂, and water vapor from air, producing oxygen-enriched output at 90-95% purity. The system operates through cyclic adsorption and vacuum desorption processes.

Product Parameters
Capacity (Nm³/h) Purity O₂ Outlet Pressure (Mpa) Inlet/Outlet Connections (mm) Dimensions (mm)
2.2 - 395%±1%0.3 - 0.5DN15/G1 21200×1000×1840
3.5 - 595%±1%0.3 - 0.5DN20/G1 21350×1200×2050
6 - 795%±1%0.3 - 0.5DN25/G1 21500×1350×2350
8 - 1095%±1%0.3 - 0.5DN25/G1 21750×1550×2300
11 - 1395%±1%0.3 - 0.5DN25/G1 21750×1550×2300
14 - 1595%±1%0.3 - 0.5DN40/G1 21850×1825×2350
16 - 1795%±1%0.3 - 0.5DN40/G1 21850×1825×2350
18 - 2095%±1%0.3 - 0.5DN40/G1 22000×1900×2350
21 - 2595%±1%0.3 - 0.5DN40/G1 22100×2050×2400
26 - 3095%±1%0.3 - 0.5DN40/G1 22100×2050×2400
31 - 3595%±1%0.3 - 0.5DN50/G12000×1300×2400
36 - 4295%±1%0.3 - 0.5DN50/G12000×1300×2800
43 - 4695%±1%0.3 - 0.5DN50/G12000×1300×2800
47 - 5295%±1%0.3 - 0.5DN50/G11800×1700×2400
53 - 5695%±1%0.3 - 0.5DN50/G1-1 22100×1800×2600
57 - 6395%±1%0.3 - 0.5DN65/G1-1 22200×1500×2700
398%±1%0.5 - 1.0DN20/G1 2/
598%±1%0.5 - 1.0DN20/G1 2/
1098%±1%0.5 - 1.0DN25/G1 2/
1598%±1%0.5 - 1.0DN25/G1 2/
2098%±1%0.5 - 1.0DN40/G1 2/
2598%±1%0.5 - 1.0DN40/G1 2/
3098%±1%0.5 - 1.0DN50/G1 2/
4098%±1%0.5 - 1.0DN50/G1/
92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power 0 92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power 1 92.5%-93.5% High Purity VPSA Oxygen Generator with 15-30 Minutes Start-Up Time and 22-110kW Air Compressor Power 2
Key Advantages
  • Instant start capability with high operational efficiency
  • Fully automated operation requiring no manual supervision
  • High-efficiency molecular sieve filling for extended service life
  • Adjustable pressure and purity settings for diverse requirements
  • Robust construction ensuring safety and stability for large-scale oxygen demand
Industrial Applications
  • Chemical manufacturing processes
  • Mining operations (gold extraction, smelting)
  • Aquaculture and fish farming systems
  • Water treatment facilities (wastewater, sewage)
  • Industrial processes (brazing, ethanol production, ozone generation)
  • Glass manufacturing furnaces
  • Biogas production facilities
  • Medical oxygen supply (hospitals, veterinary clinics)
Packaging & Delivery

Each unit is securely packaged with wooden cases and anti-collision foam blocks, wrapped in stretch film and pearl cotton according to export standards. Multiple units are shipped in 20-foot or 40-foot containers with boosters and fittings packed separately in wooden cases. All fragile components including gauges, flowmeters, and controllers receive special protective packaging.

We also manufacture PSA Oxygen Generators, storage tanks, and heat exchangers. For inquiries about VPSA Oxygen Systems or related products, please contact us at info@gneeheatex.com.

etiqueta:

Planta de oxígeno VPSA 300 Nm3/hr,

Generador de oxígeno VPSA industrial,

Planta de oxígeno con control PLC
